CNC Milling Shop

SL.NO. Name of the Machine Make / Model Table Size (mm) Stroke X/Y/Z (mm) Quantity
1 CNC Vertical Machining Centre with 5th Axis attachment BFW/BMV60+ TC24 1250x600 1050/610/960 1
2 CNC Vertical Machining Centre with 4th Axis attachment BFW/BMV60+ TC24 1250x600 1050/610/610 1
3 CNC Vertical Machining Centre with 4th Axis attachment BFW/BMV51 TC24 1000x510 800/510/510 1
4 CNC Vertical Machining Centre with Vacuum bed attachment BFW/BMV65 TC24 1500X650 1280/700/1150 1
5 CNC Vertical Machining Centre with Vacuum bed attachment and 4th Axis attachment BFW/BMV65 TC24 1500X650 1280/700/1150 1
6 CNC Vertical Machining Centre with 5th Axis attachment BFW/BMV60+ TC24 1250x600 1050/610/960 1

CNC Lathe Shop

SL.NO. Name of the Machine Make / Model Table Size (mm) Stroke X/Y/Z (mm) Quantity
1 CNC Lathe LOKESH/TL30XL Max. Turning Dia:340mm, Max. Swing Over Bed - 500mm Turning Length: With Dia 250mm, Chuck-630mm, Between Centers - 740mm 1
2 CNC Lathe LOKESH/TL200 Max. Turning Dia:240mm, Max. Swing Over Bed - 400mm Turning Length: With Dia 160mm, Chuck-300mm, Between Centers - 350mm 1
3 CNC Lathe ACE/LT-2 XL 500 Max. Turning Dia:350mm, Max. Swing Over Bed - 500mm Turning Length: With Dia 160mm, Chuck-500mm, Between Centers - 550mm 1
4 CNC Lathe ACE/Vantage 800 Max. Turning Dia: 580mm, Max. Swing Over Bed - 640mm Turning Length: With Dia 250mm, Chuck-800mm, Between Centers - 1025mm 1
5 CNC Lathe BFW/NEO 2050 Max. Turning Dia: 330mm, Max. Swing Over Bed - 500mm Turning Length: With Dia 200mm, Chuck-450mm, Between Centers - 550mm 1
6 CNC Lathe BFW/RHINO 2550 Max. Turning Dia: 360mm, Max. Swing Over Bed - 550mm Turning Length: With Dia 200mm, Chuck-497mm, Between Centers - 600mm 1

CAD/CAM

SL.NO. Software Version Quantity (LICENSE)
1 CREO 4 1
2 SOLIDWORKS 2022 1
3 MASTERCAM 2024 1

CNC EDM Shop

SL.NO. Name of the Machine Make / Model Table Size (mm) Stroke X/Y/Z (mm) Quantity
1 EDM DRILL MACHINE SPARKONIX / SPEED-II 550X350 350/250/300 (0.3MM-3MM DIA. HOLES, MAXIMUM DEPTH - 300MM) 1
2 EDM SPARK EROSION MACHINE SPARKONIX / S 50 ZNC 550X350 350/250/300 (Max. workpiece weight: 500 Kgs) 1
3 EDM WIRECUT MACHINE RUIJUN/ FR-400/S 550X680 350/400/250(Z) 1
4 CNC Marking Machine Stamp IT/ SIA1210 Head+CF-02 Column 100/120 1

Machine Shop

SL.NO. Name of the Machine Make / Model Specification, Stroke X/Y/Z (mm) Quantity
1 Vertical Milling Machine with DRO BFW /1999 450/350/350 1
2 Centre Lathe with Taper Turning attachment Kirloskar/Enterprise 1550 1000mm 1
3 Capstan Longbed Lathe Kirloskar / MK-2D 600mm 1
4 Centre Lathe Turn Master 35 Kirloskar 800mm 1
5 Capstan Lathe Gedee Weiler/MLZ-250V 250mm 1
6 Drilling Machine High Speed Eifco 13mm 1
7 Drilling Machine Eifco 13mm 1
8 Pillar Drilling & Tapping Machine Eifco / P4 38mm 1
9 Drilling Machine Eifco 10mm 1
10 Tapping Machine SKI 5mm 1
11 Surface Grinding Machine Avro 250 x 450mm 1
12 Bench Grinding Machine GAMT 250 x 500mm 1
13 Bench Grinding Machine MIDAS 1
14 Sand Blasting Machine with 15 HP Compressor Mecshot / P-9182 1
15 Power Hexa Machine UNION 250mmX250mm Sections 1
16 Power Shearing Machine SPM 610x2mm (Mild Steel) 1
17 Vertical Band Saw Machine MARU W.M.W. 18" 1
18 Heavy duty Metal Cutting Horizontal Power Band Saw Laxson / LK-2 Round 300mm Capacity, Square 250x250mm 1
19 Precision Parallel Lapping Machine Paraflat/ ULM 10 Dia.250 Area Lapping 1

Press Shop

SL.NO. Name of the Machine Make / Model Machine Spefication Quantity
1 Double action Hydraulic Press Redson / 2002 125T 1
2 Hand Press Union / 1985 6T 1
3 Hand Press Sony 2T 1
4 Down Stroking Deep Drawing Hydraulic Press with Die cushion Model RSC/DC 160 X 60 Redson / 2022 160T 1

Heat Treatment Shop

SL.NO. Name of the Machine Make / Model Machine Spefication Quantity
1 Coil type Forced Air Circulation Furnace with automatic controller CUSTOM Dia 700 x 950mm Deep 1
2 Coil type Forced Air Circulation Furnace with automatic controller CUSTOM Dia 800 x 950mm Deep 1
3 Coil type Annealing Furnace with automatic controller CUSTOM 650mm x 1050mm x 1200mm 1
4 Coil type Hardening Furnace with automatic controller and CHINO recorder CUSTOM Dia 750mm x 800mm Deep 1
5 FSA Digital motorized Hardness Testing Machine Fine / TRS-DN Digital Motorized 1
6 FSA Rockwell Cum Brinell Hardness Testing Machine Fine / MRB‐250 Mechanical 1
7 Electric Wire Rope Hoist with trolley R.P.LIFTING ENGINEERS/0.75Ton 24m/min 1
8 Centrifugal Oil Cleaning System Oilmax/OCS 1500 1500 LPH 1
9 COOLING TOWER, FRP BASIN UNITED ENGINEERING SYSTEMS, HYD 100 TR FRP 1
10 Round Vibratory Finishing Machine Surface Technik/STN-400 3HP 1

Welding Shop

SL.NO. Name of the Machine Make / Model Machine Spefication Quantity
1 AC/DC Tig Welding Machine Esab ORIGO TIG 3000I AC/DC, Water Cooled 1
2 DC Tig Welding Machine ESAB TIG 401iW DC, Water Cooled 1
3 DC Tig Welding Machine ESAB ROGUE ET 200iP DC, Air Cooled 1
4 SPM FOR ROTATING FUSION WELDING IS ENGINEERS MAX 200 DIA 1
5 ARC Welding Machine ADWANI 450 KVA 1

Captive Power

SL.NO. Name of the Machine Make / Model Machine Spefication Quantity
1 Diesel Generator Set Kirloskar/6K1080TA 160KVA 1
2 Reciprocating Compressor Elgi 15 HP 1
3 Screw Compressor Elgi/ EN11-9.5 15 HP 1
